The UV-150 Integrator tester is a high quality UV measuring instrument. It is used to measure UV energy of different light sources, especially on printing machines. It is ideal to ensure quality control of printing and drying processes.
The UV-Integrator 150 Energy Meter is used to measure UV energy and UV does of different light sources, especially on printing machines. It is ideal to ensure quality control of printing and drying process.
Technical Data:
Spectral range: UV 250-410nm
Measuring range: 0 to 5,000 mW/cm2
Display range: 0 to 999,999 mJ/cm2
Display: 6-digit LCD
Power source: long-life 3.6V Lithium Battery
Power consumption: 100uA
Battery service life: 10,000hrs
Dimensions: 3.5” (90mm)φ, 0.5” (12mm) height
Weight: approx5.5 oz(150 gr.)
Temperature range: 0 to 70 Centigrade
Temperature range: 0 to 45°Celsius
While on the conveyer belt, the UV-Integrator 150 can withstand max. 230° F(110°C) for up to 1O seconds.
Heat protection: Heat shield on back plate
Base Accuracy: +-5 %
Instruction for use:
1.Switch on the UV-Integrator 150.
The display will show “0”
2.Place the UV-Integrator 150 with the front facing the conveyer belt.
The sensor is on the back.
The back plate of the UV-Integrator 14 serves as the heat shield.
3.After the UV-Integrator 150 has passed through the conveyer, take the UV-Integrator from the conveyer belt in order to read the measuring result.
The measuring results are shown as: mJ/cm2
4.Prior to new measuring sequence, it is necessary to switch “off" and then “on” again.
This will reset the display to “0”.
Continue as described in Step 2.
Calibration:
In order to keep its full function and precision it is recommended to have re-calibration done once per year.
Re-calibration will also be necessary after change of battery.
Warranty:
1 years from the date of purchase.
